Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 36V - 300mA ± 5%
Surge→4KV
Efficiency→88%
Power Factor→0.97
Dimension mm →42 X 27 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 75V/220mA ± 5%
Surge→4KV
Efficiency→88%
Power Factor→0.99
Dimension mm →39 X 29 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 72V/220mA ± 5%
Surge→4KV
Efficiency→89%
Power Factor→0.98
Dimension mm →36 X 29 X 14
Specifications :
Input Voltage →AC/DC 12 to 24V
O/P Voltage & Current → 12V / 650mA ± 5%
Surge→2.5KV
Efficiency→95%
Power Factor→0.65
Dimension mm →25 X 21 X 16
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 36 - 84V/95mA ± 5%
Surge→4KV
Efficiency→85%
Power Factor→0.99
Dimension mm →50 X 41 X 17
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 45 - 63V/75mA ± 5%
Surge→2.5KV
Efficiency→85%
Power Factor→0.65
Dimension mm →28 X 19 X 15
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 90V/90mA ± 5%
Surge→4KV
Efficiency→87%
Power Factor→0.99
Dimension mm →30 X 25 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P 66 - 72V/105mA ± 5%
Surge→4KV
Efficiency→89%
Power Factor→0.99
Dimension mm →30 X 16 X 25
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 60V/120mA ± 5%
Surge→4KV
Efficiency→91%
Power Factor→0.99
Dimension mm →35 X 29 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 90V/90mA ± 5%
Surge→4KV
Efficiency→84%
Power Factor→0.99
Dimension mm →38 X 23 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 72V/280mA ± 5%
Surge→4KV
Efficiency→90%
Power Factor→0.99
Dimension mm →51 X 26 X 15
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 60V/120mA ± 5%
Surge→4KV
Efficiency→87%
Power Factor→0.99
Dimension mm →30 X 25 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P AC / DC 66 - 72V/265mA ± 5%
Surge→4KV
Efficiency→89%
Power Factor→0.99
Dimension mm →41 X 16 X 27
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 75V/160mA ± 5%
Surge→4KV
Efficiency→89%
Power Factor→0.99
Dimension mm →29 X 25 X 14
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 63 - 72V/270mA ± 5%
Surge→4KV
Efficiency→91%
Power Factor→0.99
Dimension mm →58 X 16 X 29
Specifications :
Input Voltage →AC 90 to 300 V
O/P Voltage & Current → O/P DC 12V/550mA ± 5%
Surge→2.5KV
Efficiency→62%
Power Factor→0.99
Dimension mm →56 X 18 X 29
